Product Description
Product description:
◆Use compressed air as a power source
◆Various diameter of extraction probes is provided to fit the use of different cars.
◆Vacuum cylinder and oil tank at the same time, increase oil extraction speed
◆The cylinder of high-grade transparency adopted can observe and measure the oil capacity primarily.
◆Applies to extraction and temporary storage of all kinds of machinery and lubricants.
Specification:
Functions: Remove and extract waste fluids or oil out from the engine and etc. with a flexible PVC tube and robust CU probe. Power from compressed air
| Function | collect waste oil from vehicle gearbox or engine |
| Power | Compressed air |
| Air Consumption | About 200L/min |
| Air Inlet Pressure(for vacuum) | 87~116PSI/6~8Bar |
| Oil ejection pressure | 10~14PSI/0.7~1Bar |
| Vacuum Degree | 0 ~ -14PSI/0~-1Bar |
| Tank Capacity | 80L |
| Height | About 950mm |
| Working Temperature | 40~60℃(for engine oil) |
