Description
Product description:Â Â Â Â Â Â Â
â—†Use compressed air as power source
â—†Various diameter of extraction probes are provided to fit the use of different cars.
â—†Vacuum cylinder and oil tank at a same time, increase oil extraction speed
â—†The cylinder of high grade transparency adopted can observe and measure the oil capacity primarily.
â—†Applies to extraction and temporary storage of all kinds of machineryand lubricants.
Specification:
Functions: Remove and extract waste fluids or oil out from the engine and etc. with a flexible PVC tube and robust CU probe. Power from compressed air
| Tank capacity | 80L |
| Collection bowl capacity | 16L |
| Air inlet pressure | 6-8Bar |
| Air inlet connection | 1/4” |
| Air pressure for oil discharge | 0.7~1Bar |
| Vacuum degree | -1~0Bar |
| Oil temperature range | 40-60℃ |
| Suction Speed(max.) | 6.5Liter/m |
| N/G weight | 18.5/21.5kgs |
| Package dimension | 440*440*1000mm |
