Description
Product description:Â Â Â Â Â Â Â
1.Vacuum&Explosion-proof integrated mechanism(Patented)
2. Modular Cylinder(Patented)
3. Tool tray
4. Damage-free lifting rod locking mechanism
5. Liquid level display cover(Patented)
6. Waste oil collection
7. Resistant PVC wheel
Specification:
Functions: Remove and extract waste fluids or oil out from the engine and etc. with a flexible PVC tube and robust CU probe. Power from compressed air
| Tank capacity | 80L |
| Collection bowl capacity | 16L |
| Modular cylinder capacity | 10L |
| Air inlet pressure | 6-8Bar |
| Air inlet connection | 1/4” |
| Air pressure for oil discharge | 0.7~1Bar |
| Vacuum degree | -1~0Mpa |
| Oil temperature range | 40-60℃ |
| Suction Speed(max.) | 6.5Liter/m |
| N/G weight | 18.5/21.5kgs |
| Package dimension | 470*440*960mm |
